2007 Ford F-150 Oil Pressure Sensor Replacement

REPAIR ORDER RECORD

1. Repair Type: Mechanical Repair / Electrical
2. Repair Date: 08/05/2026
3. Vehicle System / Component: Engine Lubrication / Instrument Cluster
4. Customer Concern / Complaint (3-C's): Intermittent oil pressure gauge failure (reading zero) and active oil leak observed from the engine block area.
5. Diagnostic Findings / Cause (3-C's): Verified engine mechanical oil pressure at 65 PSI. Inspection revealed the previously installed oil pressure sensor was the incorrect component (intended for a Mustang application), featuring an input shaft that was too short for the F-150 housing. This mismatch caused both the intermittent signal loss and an external fluid leak. A secondary leak was also identified at the Fram oil filter.

1. Corrective Action / Labor (3-C's):Removed the incorrect sensor using a 13/16 inch wrench.
2. Installed the correct Duralast PS407 Engine Oil Pressure Switch (obtained as a warranty replacement).
3. Cleaned residual oil from the engine block surface.
4. Verified that the dashboard oil pressure gauge returned to the normal operating range.

1. Parts and Fluids Used:
2. Duralast Engine Oil Pressure Switch (Part # PS407)
3. Service Notes / Tips:
4. Vehicle Details: 2007 Ford F-150 4.2L (215,000 miles).
5. Tooling: Installation requires a 13/16 inch wrench.
6. Future Maintenance: The Fram oil filter is currently leaking and should be replaced during the next oil change service.
7. Service performed by: Paul (Home Mechanic).
